Eagle Acura B18A/B B20B Engine (Length=5.394) Connecting Rods (Set of 4)

Eagle Rods

  • $369.99


Eagle CRS5394A3D ESP 4340 Forged H-Beam Connecting Rods Honda B18/B20

Eagle offers their ESP H-beam connecting rods in a lightweight series. Their lighter weight design provides less rotating mass for flawless high-rpm performance. Their 2-piece, forged, vacuum-degassed, 4340-certified steel construction provides superb strength at a fraction of the weight of most other rods. Each rod is multi-stage heat-treated, X-rayed, sonic-tested, magnafluxed, 100 percent machined, and shot-peened to stress-relieve the metal. The rods have a stout cap screw attachment with precision cap alignment sleeves to positively locate each rod cap.

Specifications:



  • Fasteners: 3/8"" ARP 2000
  • Torque: 43 ftlbs with ARP moly lube on threads
  • Pin fit: Bushed
  • Recommended up to 900 HP



Dimensions:



  • Length: 5.394 in.
  • Rod journal: 1.771 in.
  • Housing bore: 1.8900 in.
  • Pin size: 0.827 in.
  • Big end width: 0.9350 in.
  • Pin end width: 0.9350 in.
  • Thickness above pin: 0.200 in.
  • Typical weight: 535g



Notes: Standard rod for B18A, B18B, B20B, B20Z. Older design used 5/16" bolt (3/8" head) - torque was 28 ftlbs with moly lube.
