Rywire OBD1 Budget D & B-series Tucked Engine Harness
MADE IN THE U.S.A.
This harness uses Mil-Spec Teflon coated wire with a maximum heat rating of 200°C.
Vehicle Type: Select your vehicles chassis type.
This tells us what interior "Chassis Adapter" to use for your setup.
Our Budget D-series and B-series compatible wire-tuck engine harness is nearly identical to our Mil-spec engine harness line with the primary difference being, the single black wire color and expandable loom used. There are quite a few options available. Please look through them carefully to make sure you get the right parts!
All connectors and materials are new. Each connector is crimped with pneumatic heads to ensure an OEM crimp every time, then tagged with a white identification label for easy installation. All heavy interference circuits are protected and grounded with proper wire covering. Our engine harnesses are 100% quality tested pin to pin; And resistance checked to ensure no voltage fluctuations.
All Rywire engine harnesses are made with OBD1 (92-95) ECU Connectors. An ECU adapter can be used for OBD2 ECU's if necessary however our harness does not support USDM OBD2 ECU's. Aftermarket ECU's using OBD2 plugs and Non-US OBD2 ECU's are compatible (except for H22 and GSR stock computers). CONTACT US FOR OPTIONS.
Each harness will come with a custom back side sub-harness that will be proprietary to the chassis you choose on the drop down menu. This way if you ever change chassis you will only need a new sub-harness, not a whole new wire loom!
These harnesses are warrantied and guaranteed to work, however they are non-refundable if installed. Because the back-side (interior/shock tower connection) separates from the main harness, the engine harness can be used on multiple chassis provided the engine itself uses the same components. We sell the back-side harness separately only over the phone for previous engine harness customers.
HARNESS CONNECTOR LIST:
INSTRUCTIONS
All connectors and materials are new. Each connector is crimped with pneumatic heads to ensure an OEM crimp every time, then tagged with a white identification label for easy installation. All heavy interference circuits are protected and grounded with proper wire covering. Our engine harnesses are 100% quality tested pin to pin; And resistance checked to ensure no voltage fluctuations.
All Rywire engine harnesses are made with OBD1 (92-95) ECU Connectors. An ECU adapter can be used for OBD2 ECU's if necessary however our harness does not support USDM OBD2 ECU's. Aftermarket ECU's using OBD2 plugs and Non-US OBD2 ECU's are compatible (except for H22 and GSR stock computers). CONTACT US FOR OPTIONS.
Each harness will come with a custom back side sub-harness that will be proprietary to the chassis you choose on the drop down menu. This way if you ever change chassis you will only need a new sub-harness, not a whole new wire loom!
These harnesses are warrantied and guaranteed to work, however they are non-refundable if installed. Because the back-side (interior/shock tower connection) separates from the main harness, the engine harness can be used on multiple chassis provided the engine itself uses the same components. We sell the back-side harness separately only over the phone for previous engine harness customers.
HARNESS CONNECTOR LIST:
| • Oil Pressure Sending Unit | • Knock Sensor | • Intake Air Temperature (Intake Manifold Style) |
| • Oxygen Sensor (Primary 4 Wire) | • Alternator | • 2 Extra Wires |
| • Injector 1-4 | • MAP Sensor |
• TPS (Throttle position) |
| • Idle Control Motor | • Electronic Speed Sensor | • Ground |
| • Fan Switch |
• OBD1 Distributor plugs |
• H20 Sending Unit (for Gauge Cluster) |
| • Reverse Lights VTEC solenoid |
• Engine Coolant Temp | • Starter Signal |
